T5300T TILT-TOWER TIRE CHANGER

Built to get the job done with less hassle, the John Bean® T5300T is a powerful machine that performs core tire-changing duties with ease.

Utilizing a proven tilt-tower design, the T5300T provides ample clearance to easily load tires onto the turntable. The T5300T uses an ergonomically positioned pedal that operates a powerful, easy-to-operate bead breaker shovel to break the bead on traditional high-aspect tires easily.

Practical and effective, the T5300T is a tilt-tower tire changer that is capable and ready to go to work.

Features

TILT-TOWER

The pneumatic tilt-back post provides maximum clearance for installing the tire on the turntable.

ON-FLOOR BEAD BREAKER (PEDAL-OPERATED)

Traditional side-shovel bead breaker with ergonomic pedal-control positioned away from the shovel; the fastest solution for standard, soft sidewall, and high-aspect tires.

TABLETOP BEAD SEATER

A direct burst of compressed air comes through the clamping jaws to facilitate bead seating.

DOWNLOADS

TECH SPECS

Part Number

EEWH569AES

Max Rim Diameter

22″  |  56cm

Max Tire Width

13″  |  33 cm

Max Rim Width

12″  |  31cm

Max Wheel Diameter

39″  |  100cm

Wheel Lift Capability

154 lbs.  |  70 kg

Power Supply

230v 1ph 50Hz 10A

Air Pressure Required

116-174 PSI  |  8-12 bar

Dimensions HxWxD

63″x73″x35″  |  160x185x90cm

ACCESSORIES

STANDARD

1 kg Lube Bucket Holder
Bead Lever Plus
Plastic Protectors

OPTIONAL

5 kg Lube Bucket Holder
Lube Brush
Bead Lever Protector Plus
Plastic Rim Protector: Clip-on Type
Bead Breaker Blade Sleeve
Light Alloy Rim Protector for Center Type Fixed Jaws - Front
Wheel Lift
