15k Four Post
Alignment Lift
PRODUCT DESCRIPTION
A sturdy 4-post lift that's decked out for the big jobs - the John Bean 15k 4-Post Alignment Lift is equipped to provide professional-grade alignment lifting for a variety of vehicle sizes.
With open-front columns, ultra-wide 26” runways, and integrated 100" long rear slip plates, this lift is ready to make light work of heavy-duty, dual-rear-wheel trucks while being equally suited to accommodate standard, four-wheel alignments on passenger vehicles. Available in two lengths: standard and extended, this lift is certified to the industry's leading ANSI/ALI automotive lift standard.
Part Number: EELR504APKG standard / EELR506APKG extended
Wide rear column clearance
- Extended rear column drive-on clearance
- 120” drive-on clearance / 125” body clearance
- Allows dual-wheel trucks to drive on without interference
- Imaging alignment compatible – easily accommodate split-roll during alignment using AC200 or AC400 clamps
Pro-style runways
- Best-in-class, ultra-wide, 26” runways for wide track width vehicles
- Ultra-low-profile allows “easy-on” approach angle for low-profile vehicles, lowered height just 8”
- Pre-assembled with pulleys, pins, cables, cylinder, pull bar for quicker installation and factory-verified fit/function
Enhanced rear slip plates
- Extra-long 100” rear slip plates for improved 4-wheel alignment capability for long and short wheelbase vehicles
- Flush mount, full-floating slip plate with Delrin® polymer ball-transfer unit, engineered for low-maintenance performance
- Rolled outside edges provide additional strength and flatness for heavy vehicles
Open front cross beam
- Easy access to service areas for hassle-free adjustments and repairs
- Micro-adjustment leveling set screws on front and rear cross beam
- Adjustable, folding 4” front wheel stops have clearance for long, low-profile vehicles
Louvered ramps
- Ultra-wide ramps with anti-slip louvered/dimpled surface
- Increased traction for improved vehicle loading, especially in wet or slick conditions
- Low approach angle ramp for easy transition from floor to alignment deck
Innovative cable brake lock
- Cartridge-based locking and cable brake system for ease of maintenance
MEDIA
TECH SPECS
Capacity | Kg |
Capacity | 15000 lbs |
Lifting times | 85 s |
Lowering times | s |
Lifting height | 78 inch |
Lifting height | mm |
Maximum pad height from floor | mm |
Maximum pad height from floor | inch |
Drive-through width | 120 inch |
Drive-through width | mm |
Motor | |
Motor | 2 Hp |
Power supply | 230V 1Ph 50/60Hz |
Distance between columns | mm |
Distance between columns | inch |
Short arm extraction | mm |
Short arm extraction | inch |
Long arm extraction | mm |
Long arm extraction | inch |
Minimum ceiling height | mm |
Minimum ceiling height | inch |
Minimum concrete thickness | mm |
Minimum concrete thickness | 4 inch |
Net weight | 4550 lbs |
Width Between Runways | 40.625 inch |
4 Wheel Alignment Wheelbase | 68-158 inch |
2 Wheel Alignment Wheelbase | 167.75 (standard) / 195.25 (extended) inch |
Console Dimensions DxWxH | inch |
Air Supply Requirements | 90-120 Psi |
Front Accessibility | open |
Overall Length | 250.75 (standard) / 277 (extended) inch |
Service Wheelbase | 183 (standard) / 210.5 (extended) inch |
Overall Width | 142 inch |
Column Height | 98 (rear) / 99.25 (front) inch |
Column Width | inch |
Column Depth | inch |
Height of Lifting Fork | inch |
Length of Fork | inch |
Lifting Capacity Per Column | 3750 lbs |
Lifting Speed | s |
Load Capacity Per Set of Four Columns | lbs |
Load Capacity Per Set of Six Columns | lbs |
Lowered Wheel Fork Height | inch |
Lowering Speed | s |
Runway Width | 26 inch |
Weight per Column | lbs |
Width of Lifting Fork | inch |
